RTIC-WP: single bank high power chargers

With a wide operating temperature range and UL/CSA1236 certification, the RTIC-WP product is especially suited for high end industrial applications and severe environments. This product series is versatile, rugged and waterproof. The RTIC-WP is factory programmable to accommodate several user defined charging algorithms. An LED display indicates charging and AC/DC status. There are also four optional user-defined signal/power relay contacts and long distance digital temperature compensation.



  • Intelligent three stage charger
  • UL/CSA 1236 certified
  • Spark-free hookup
  • Mode indicators
  • Optional control monitoring signals
  • Optional temperature compensation
  • Optional relay contacts
  • Low standby current
  • Reverse polarity protection
  • Over voltage and current protection
  • Over temperature protection
  • Rugged and waterproof
  • Fully encapsulated and hermetically sealed
  • 110 VAC or 220 VAC models







  110 VAC
  RTIC 1120-WP 12VDC @ 20 Amps manual spec sheet
  RTIC 1210-WP 24VDC @ 10 Amps manual spec sheet
  RTIC 1307-WP 36VDC @ 7 Amps manual spec sheet
  RTIC 1405-WP 48VDC @ 5 Amps manual spec sheet
  220 VAC
  RTIC 2120-WP 12VDC @ 20 Amps manual spec sheet
  RTIC 2210-WP 24VDC @ 10 Amps manual spec sheet
  RTIC 2307-WP 36VDC @ 7 Amps manual spec sheet
  RTIC 2405-WP 48VDC @ 5 Amps manual spec sheet
  O&M drawing for all RTIC-WP models
  Download IGS 3D model





Our products can be purchased from our distributors or directly from us. You can contact us at the phone number or email address below.
